Control pin functions and applications – Vicor Micro Family of DC-DC Converter User Manual
Page 12
Design Guide & Applications Manual
For Maxi, Mini, Micro Family DC-DC Converters and Configurable Power Supplies
Maxi, Mini, Micro Design Guide
Rev 4.9
vicorpower.com
Page 11 of 88
Apps. Eng. 800 927.9474
800 735.6200
DESCRIPTION
PART NUMBER
Maxi board style
24644R
Mini board style
24645R
Micro board style
24646R
Figure 2–16 — Online trim calculator
EVALUATION BOARDS
•
Three styles: Maxi, Mini or Micro
•
Short pin and Long pin compatible
•
Easy I / O and control connections
•
Includes fusing and capacitors
•
Can be paralleled for higher power arrays
2. Control Pin Functions and Applications
