Vicor VIPAC Power System 50 – 900 Watt User Manual
Vi pac, Family
Product Description
Vicor’s VIPAC is a new type of integrated power system leveraging the latest advances in
DC-DC converter technology and modular front-ends. VIPAC combines application specific
power processing units (PPU), a choice of chassis styles and remotely located hold-up
capacitors to provide fast, flexible and highly reliable power solutions for a wide range of
demanding applications.
The PPU is the core element of the system and may be specified for 115/230 Vac operation.
The PPU incorporates Vicor’s autoranging FARM modular front-end to provide transient
protection, EMI filtering and inrush current limiting. The web-based PowerBench
™
enables
designers to configure the PPU with up to three independently regulated outputs having
power levels from 50 to 500 W and with as much as 900 W total output power.
(continued)
VIPAC
TM
Family
of Power Systems
50 to 900 Watt
Description
&
Installation Guide
