Northern Connectors Harting Han-Modular Connectors - Manual (Page 97)

06
.
97
Han
Modular
"https://b2b.harting.com/ebusiness/en/
09 14 001 3011
"
"https://b2b.harting.com/ebusiness/en/
09 14 001 3111
"
"https://b2b.harting.com/ebusiness/en/
09 14 020 3113
"
M
F
32 V 4 A
"https://b2b.harting.com/ebusiness/en/
09 67 000 7576
"
"https://b2b.harting.com/ebusiness/en/
09 67 000 5576
"
"https://b2b.harting.com/ebusiness/en/
09 67 000 8576
"
"https://b2b.harting.com/ebusiness/en/
09 67 000 7476
"
"https://b2b.harting.com/ebusiness/en/
09 67 000 5476
"
"https://b2b.harting.com/ebusiness/en/
09 67 000 8476
"
M
F
"https://b2b.harting.com/ebusiness/en/
09 14 020 3013
"
Module
Part-Number
Han ® Shielded module
Identification Male insert (M) Female insert (F) Drawings Dimensions in mm
Number of contacts
20
Identification mm² Male contacts (M) Female contacts (F) Drawings Dimensions in mm
Wire gauge Part-Number
Han ® Shielded module
insert
20 + shield
crimp contacts order
separately
0.08-0.21
0.13-0.33
0.33-0.52
Han ® D-Sub crimp contacts
gold plated
Wire gauge ø Stripping
length of
stranded wire
0.08 - 0.21 mm²
0.13 - 0.33 mm²
0.33 - 0.52 mm²
AWG 28-24
AWG 26-22
AWG 22-20
4 mm
4 mm
4 mm
Contact
arrangement
View
termination side
Stock items in bold type
