Han-modular, Docking frame – Northern Connectors Harting Han-Modular Connectors User Manual
Page 18
06
.
18
Han
Modular
"
"
Han-Modular
®
Docking frame
Stock items in bold type
Part number
Identification
Marking A ... F Marking a ... f
Drawing
Dimensions in mm
Docking frame
for 6 modules
float mount
① floating tolerance ±2 mm
Docking frame
for 6 modules
fixed
Panel cut out
Docking frame
for 4 modules
float mount
① floating tolerance ±2 mm
Docking frame
for 4 modules
fixed
Panel cut out
