background image

06

.

122

Han

Modular

Han-Elisa

®

ID module

Features

• Coding of tools possible (e.g. press tools) by

means of an alphanumeric identification

• I²C bus EEPROM as memory medium

• Communication with PLC via conventional digital

I/Os

• Physical connection of PLC by means of well-

proven Han

®

contacts

• Assembly of the ID module to the device by

means of a Han

®

industrial connector

Technical characteristics

Inserts

Supply voltage

24 V

via digital I/O device

Electrical connector, 24 V

Han E

®

module

(see page 06.52)

Memory capacity

max. 128 Byte

Material

polycarbonate

Working temperature

0 °C ... +70 °C

Stock temperature

0 °C ... +85 °C

Max. length recommended

between I/O device

and ID module

100 m *

General description

The HARTING connector identification module (ID module) is suitable for storing of data and for coding of connectors. It is integrated

in a Han-Modular

®

standard E module.

The module can be connected to a 24 V digital I/O device of a PLC. Two digital inputs are used for detecting the module connec-

tion and the data input. Two digital outputs are used for the data output and the system clock. Furthermore the ID module must be

connected with 24 V and GND. Communication is carried out with voltage levels of 24 V according to the I²C bus standard. The total

memory capacity is 128 Byte, e.g. for storing part numbers to identify the module. It is also possible to store the start parameters or

operating data for machine components.

A typical data structure is displayed in the following table:

Byte no.

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

Check sum

Operating hours of tool

Start parameter of the unit

Part number of the unit

Applications for the ID module can be found in modular machines and product lines. A great advantage of the ID module is the non

volatile decentralized storing of e.g. operating data. When changing the location stored data can protect the machines from damages.

In service cases of the equipment data can be analyzed to minimize service time.

* The use of shielded cables is recommended for

longer distances or EMC loaded environments.
