Han ® D-Sub module
Features
• 9-pin D-Sub connector of the Han-Modular ® system
• Ideal for the transmission of sensetive signals
• Compatible to crimp, solder or IDC termination
• Using of guiding pins (male and female) is
recommended (see chapter 95).
Technical characteristics
Specifications DIN EN 60 664-1
DIN EN 61 984
Approvals
Inserts
Number of contacts 9
Electrical data
acc. to EN 61 984
5 A 50 V 0.8 kV 3
Rated current 5 A
Rated voltage 50 V
Rated impulse voltage 0.8 kV
Pollution degree 3
Rated voltage
acc. to UL < 30 V
Insulation resistance ≥ 10 10 Ω
Material polycarbonate
Limiting temperatures -40 °C ... +125 °C
Flammability acc. to UL 94 V 0
Mechanical working life
- mating cycles ≥ 500
