06

.

94

Han

Modular

Technische Kennwerte

Features

Technical characteristics

Han

®

MegaBit Module

• Shielding bus separate from housing potential
• Suitable for Ethernet Cat. 5e
• Suitable for Han B, Han M, Han EMC and Han

HPR hoods/housings, high construction

Specifications

DIN EN 60 664-1

DIN EN 61 984

Han

®

module adapter

Number of contacts

2 x 4

Insulation resistance

≥ 10

10

Material Polycarbonate
Limiting temperatures

-40 °C ... +125 °C

Flammability acc. to UL 94

V 0

Mechanical working life

≥ 500 mating cycles

Han

®

MegaBit

insert

Number of contacts

2 x 4 + shielding

Electrical data acc. to

DIN EN 61 984

10 A 50 V 0.8 kV 3

Rated current

10 A

Rated voltage

50 V

Rated impulse voltage

0.8 kV

Pollution degree

3

Material

- insulator

Polycarbonate

- outer conductor

Zinc alloy

Contact resistance

≤ 4 mΩ

Limiting temperatures

-40 °C ... +125 °C

Flammability acc. to UL 94

V 0

Outer surface finish

Nickel

Cable diameter

5 ... 12 mm

Han D

®

crimp contacts

Material

Copper alloy

Surface

- hard gold plated

3 µm Au over 3 µm Ni

Contact resistance

≤ 3 mΩ

Crimp terminal

- mm²

0.14 ... 2.5 mm²

- AWG

26 ... 14

Accessories

Crimp flange

see page 06.98

Crimp ferrule

see page 06.98

Cable clamp

see page 06.98
