Han-Modular ® Hinged frames
Features
• Pre-leading grounding system according VDE
• Modules can only be assembled polarized to
guarantee a correct orientation
• Alphabetical marking of module position
• High mechanical reliability of modules in case of
vibration and impact stress
• No tools necessary to remove modules
Technical characteristics
Specifications DIN EN 60 664-1
DIN EN 61 984
Approvals , ,
Hinged frames
Number of modules 2, 3, 4, 6
PE contact
Wire gauge
- Power side * 4 ... 10 mm²
AWG 12 ... 8
- Signal side 1 ... 2.5 mm²
AWG 18 ... 14
Material zinc die-cast
Limiting temperatures -40 °C ... +125 °C
Mechanical working life
- mating cycles ≥ 500
Hoods/Housings
Selection of hoods/housings see chapter 31
Material aluminium die-cast
Surface powder-coated
RAL 7037
Locking element Han-Easy Lock ®
Hoods/Hosuings seal NBR
Limiting temperatures -40 °C ... +125 °C
Degree of protection acc. to DIN EN 60 529
for coupled connector IP 65
Accessories
Coding of hoods/housings chapter 95
* 10 mm² / AWG 8 only with ferrule crimp tool
