Han-Elisa ® Pt100 module
Features
• Minimum size for integration in Han ® industrial
connectors (Han-Modular ® and Han-Snap ® )
• Economy of space by reduction the number of
terminal blocks and interface modules in the
switch cabinet
• Male module for signal input
Technical characteristics
Inserts
Sensor Pt100 acc. to IEC 751
Termination technology 2-, 3-, 4 wire technology
Sensor input current 0.8 mA, constant
Conductor resistance, max. permissible 10 Ω per conductor
Min. measuring range 100 °C
Open circuit detection integrated
Material polycarbonate / LCP
Termination Cage-clamp terminal
- mm² 0.14 ... 1.5 mm²
- AWG 26 ... 16
Power diagnostic LED (green)
Temperature range
Working temperature -20 °C ... +65 °C
Stock temperature -40 °C ... +85 °C
