100 a single module – Northern Connectors Harting Han-Modular Connectors User Manual
Page 32

06
.
32
Han
Modular
Han
®
100 A Single Module
Features
Technical characteristics
• Crimp or axial screw termination available
• Unlock the contacts from mating side with a screw
driver or removal tool
• Separate axial screw contacts can be terminated
without any special tools directly to the wire
Specifications
DIN EN 60 664-1
DIN EN 61 984
Inserts
Number of contacts
1
Electrical data
acc. to EN 61 984
100 A 830 V 8 kV 3
Rated current
100 A
Rated voltage
830 V
Rated impulse voltage
8 kV
Pollution degree
3
Insulation resistance
≥ 10
10
Ω
Material
polycarbonate
Limiting temperatures
-40 °C ... +125 °C
Flammability acc. to UL 94
V 0
Mechanical working life
- mating cycles
≥ 500
Max. insulation diameter
13 mm
Crimp Contacts
Material
copper alloy
Surface
- hard-silver plated
3 µm Ag
Contact resistance
≤ 0.3 mΩ
Crimp terminal
- wire gauge
10 ... 35 mm²
Axial Screw Contacts
Material
copper alloy
Surface
- hard-silver plated
3 µm Ag
Contact resistance
≤ 0.3 mΩ
Screw terminal
- wire gauge
1)
10 ... 35 mm²
- AWG
6 ... 2
- hexagonal driver
SW 4
- tightening torque
mm²
10 16 25 35
Nm
6
6
7
8
1) geometric wire gauge
