Han

®

200 A Crimp module

1000 V 200 A

Stock items in bold type

Number of contacts

1

Part number

Identification

Male insert (M) Female insert (F)

Drawing

Dimensions in mm

Crimp terminal

Modul

Wire gauge

Part number

Identification

(mm²)

Male contact Female contact

Drawing

Dimensions in mm

Crimp contacts*
silver plated

Wire gauge

Stripping length

A

7

8.2

10

11.5

19 mm

20 mm

22.5 mm

22.5 mm

for stranded wire according to IEC 60 228 Class 5

* Crimp zone acc. to DIN EN 46 235

Removal tool

for TC contacts

in 200 A crimp module
