HV Single module

Features

• Suitable for Han

®

E crimp contacts

• 2 contacts up to 2500 V
• Insulator out of a voltage resistant teflon material
• Combination with all other modules (pneumatic,

signal etc.) is possible

Technical characteristics

Specifications

DIN EN 61 984

DIN VDE 0115

DIN EN 60 664-1

Inserts

Number of contacts

2

Electrical data

acc. to EN 61 984

16 A 2500 V 15 kV 3

Rated current

16 A

Rated voltage

2500 V

Rated impulse voltage

15 kV

Pollution degree

3

Insulation resistance

≥ 10

10

Ω

Material

Polycarbonate/Teflon (PTFE)

Limiting temperatures

-40 °C ... +125 °C

Flammability acc. to UL 94

V 0

Mechanical working life

- mating cycles

≥ 500

Contacts

Material

Copper alloy

Surface

- hard-silver plated

3 µm Ag

- hard gold platet

2 µm Au over 3 µm Ag Ni

Contact resistance

≤ 1 mΩ

Crimp terminal

- mm²

0.5 ... 4 mm²

- AWG

20 ... 12
