Han

®

70 A Axial module

1000 V 70 A

Identification

Part number

Drawing

Dimensions in mm

Stock items in bold type

Number of contacts

2

Part number

Identification

Male insert (M) Female insert (F)

Drawing

Dimensions in mm

Axial screw terminal

70 A

6 ... 16 mm²

14 ... 22 mm²

Hex key SW 2.5

for axial setscrew

Bit 1/4“

Axial screw terminal

70 A

with finger protected male

contacts
