06

.

16

Han

Modular

Han-Modular

®

Docking frame

Features

• Blind mating connector system for drawer systems

• Direct panel mounting without housing

• Very robust design

• Solid pre-leading guid pins and float bushes

• Can be fixed with standard M4 screws

Notice:

Due the plastic material used in the docking frame

without PE, the panel will need to be grounded sepa-

rately

Technical characteristics

Specifications

DIN EN 60 664-1

DIN EN 61 984

Docking frames

Number of modules

2, 3, 4, 6

Material

- Docking frames

polycarbonate

- Float washer

zinc die-cast

Floating tolerance

± 2 mm

Aligning tolerance

± 4 mm

Limiting temperatures

-40 °C ... +125 °C

Flammability acc. to UL 94

V 0

Mechanical working life

- mating cycles

≥ 500
