Han-Modular

®

ECO

"https://b2b.harting.com/ebusiness/en/

09 14 001 0421

"

"https://b2b.harting.com/ebusiness/en/

09 14 001 0423

"

"https://b2b.harting.com/ebusiness/en/

09 14 001 0321

"

"https://b2b.harting.com/ebusiness/en/

09 14 000 9929

"

"https://b2b.harting.com/ebusiness/en/

09 14 001 0721

"

"https://b2b.harting.com/ebusiness/en/

09 14 001 0723

"

Stock items in bold type

Plastic hoods/housings
with PE marking

Identification

Part number

Drawing

Dimensions in mm

Hoods

with PE marking

(pin 1 = PE)

IP 65

top entry

Hoods

with PE marking

(pin 1 = PE)

IP 20

top entry

Housing, bulkhead mounting

with PE marking

(pin 1 = PE)

IP 20 / IP 65

Panel cut out

Coding pin

Range of delivery:

8 pieces per frame

Cable to cable hoods

with PE marking

(Pin 1 = PE)

top entry

IP 20

IP 65
