Han ® 40 A Axial module
1000 V 40 A
Identification Part number Drawing Dimensions in mm
Stock items in bold type
Number of contacts
2
Part number
Identification Male insert (M) Female insert (F) Drawing Dimensions in mm
Axial screw terminal
40 A
Contact arrangement view from termination side
2.5 ... 8 mm²
6 ... 10 mm²
Hex key SW 2
for axial setscrew
with grip
Bit 1/4“
