Han ® RJ45 module Patch cables
Features
• Locking lever protection for RJ45 connector latch
• Very short plug design in combination with robust
bend protection
• RoHS compliant
• Fully EMC screened (aluminium-clad foil and braid)
Technical characteristics
Specifications ISO/IEC 24 702
ISO/IEC 11 801
ISO/IEC 61 935-2
Cat. 5 e RJ45 patch cable
Transmission features Category 5 /
Class D up to 100 MHz;
acc. to ISO/IEC 24 702
or ISO/IEC 11 801
Transmission rate 10/100/1000 Mbit/s
Cable type 1:1 EIA/TIA 568 B, 8 poles
Material cables SF/UTP, PUR, yellow
Limiting temperatures
- mobile 0 °C ... +60 °C
- stationary -40 °C ... +80 °C
Flammability flame retardant, halogen-free
Degree of protection IP 20
Cat. 6 RJ45 patch cable
Transmission features Category 6 /
Class E up to 250 MHz;
acc. to ISO/IEC 24 702
or ISO/IEC 11 801
Transmission rate 10/100/1000 Mbit/s
Cable type 1:1 EIA/TIA 568 B, 8 poles
Material cables SF/UTP, PUR, yellow
Limiting temperatures
- mobile 0 °C ... +60 °C
- stationary -20 °C ... +80 °C
Flammability flame retardant, halogen-free
Degree of protection IP 20
