Northern Connectors Harting Han-Modular Connectors - Manual (Page 55)

06
.
55
Han
Modular
"https://b2b.harting.com/ebusiness/en/
09 14 006 2733
" "https://b2b.harting.com/ebusiness/en/
09 14 006 2633
"
M
F
Han ® E Quick Lock module
500 V 16 A Han- Quick Lock ®
Number of contacts
6
Part number
Identification Male insert (M) Female insert (F) Drawing Dimensions in mm
Quick Lock termination
Contact arrangement
view from
termination side
Stock items in bold type
