Han

®

HV module

2900 / 5000 V 16 A

Stock items in bold type

Number of contacts

2

Part number

Identification

Male insert (M) Female insert (F)

Drawing

Dimensions in mm

Crimp terminal

Order crimp contacts

separately

Range of delivery:

- 1 module

- 2 locking sleeves

- 2 heat shrink tubes

Removal tool

for locking sleeve

Wire gauge

Part number

Identification

(mm²)

Male contact Female contact

Drawing

Dimensions in mm

Crimp contacts

Operating contact

Identification

Identification

Wire gauge

Stripping

length

no groove

1 groove*

1 groove

2 grooves

3 grooves

wide groove

no groove

0.5

0.75

1

1.5

2.5

3

4

9.5 mm

9.5 mm

9.5 mm

9.5 mm

9.5 mm

9.5 mm

9.5 mm

* on the back crimp collar

silver plated

0.5

0.75

1

1.5

2.5

3

4
