Han ® RJ45 module RJ Industrial
Features
Han-Modular ® RJ Industrial RJ45 connector set
• Conforming to the RoHS directive
• 360° shielded contact
• Field assembly without tools possible by means of
HARAX ® rapid termination in IDC technology
• Suitable for termination of massive and flexible
wires
Han-Modular ® RJ Industrial Gigalink RJ45 connector set
• Conforming to the RoHS directive
• 360° shielded contact
• Field assembly by means of piercing contacts
• Suitable for termination of flexible wires
Technical characteristics
Specifications IEC 60 603-7
DIN EN 60 664-1
DIN EN 61 984
HARTING RJ Industrial ® , 4 pins
Number of contacts 4
Transmission features Category 5 /
Class D up to 100 MHz;
acc. to ISO/IEC 11 801:2002
and EN 50 173-1
Transmission rate 10/100 Mbit/s
Wire termination IDC contacts; without tools
Terminated cable
- Conductor cross section
flexible AWG 24/7 ... AWG 22/7
solid AWG 23/1 ... AWG 22/1
- Cable outside diameter ≤ 1.6 mm
Material insert polyamide
Limiting temperatures -40 °C ... +70 °C
HARTING RJ Industrial ® 10G, 8 pins
Number of contacts 8
Transmission features Category 6 /
Class E up to 250 MHz;
acc. to ISO/IEC 11 801:2002
and EN 50 173-1
Transmission rate 10/100 Mbit/s and 1/10 Gbit
Wire termination IDC contacts; without tools
Terminated cable
- Conductor cross section
flexible AWG 27/7 ... AWG 22/7
solid AWG 27/1 ... AWG 22/1
- Cable outside diameter ≤ 1.5 mm
Material insert polyamide
Limiting temperatures -40 °C ... +70 °C
HARTING RJ Industrial ® Gigalink, 8 pins
Number of contacts 8
Transmission features Category 6
A
/
Class E
A
up to 500 MHz;
acc. to ISO/IEC 11 801:2002
and EN 50 173-1
Transmission rate 10/100 Mbit/s and 1/10 Gbit
Wire termination Piercing contacts
Terminated cable
- Conductor cross section
flexible AWG 28/7 ... AWG 24/7
- Cable outside diameter ≤ 1.05 mm
Material insert polyamide
Limiting temperatures -40 °C ... +70 °C
