RJ45 module

Technical characteristics

Features

• Single module with standard shielded RJ45 plug

and jack

• Cat 6 for all data pairs (all 8 pins)

• Conforming to the RoHS directive

• The RJ45 inserts are protected by a reliable

plastic insulator

• Patch cables are assembled/removed without

tools

Technical characteristics

Specifications

DIN EN 60 664-1

DIN EN 61 984

Approvals

Inserts

Number of contacts

8

Electrical data

acc. to EN 61 984

1 A 50 V 0.8 kV 3

Rated current

1 A

Rated voltage

50 V

Rated impulse voltage

0.8 kV

Pollution degree

3

Rated voltage

acc. to UL

< 30 V

Transmission features

Category 6 /

Class E up to 250 MHz;

acc. to ISO/IEC 11 801:2002

and EN 50 173-1

Transmission rate

10/100/1000 Mbit/s

Insulation resistance

≥ 10

10

Ω

Material

polycarbonate

Limiting temperatures

-40 °C ... +85 °C

Flammability acc. to UL 94

V 0

Mechanical working life

- mating cycles

≥ 500
