06

.

96

Han

Modular

Technische Kennwerte

Features

Technical characteristics

Han

®

Shielded module

• Data bus shielding separated from housing
• Ideal for the transmission of very sensitive signals

(e.g. bus signals)

Specifications

DIN EN 60 664-1

DIN EN 61 984

Han

®

Module adapter

Number of contacts

20 + shield

Insulation resistance

≥ 10

10

Material Polycarbonate
Limiting temperatures

-40 °C ... +125 °C

Flammability acc. to UL 94

V 0

Mechanical working life

≥ 500 mating cycles

Shielded insert

Electrical data acc. to

DIN EN 61 984

4 A 32 V 0.8 kV 3

Rated current

4 A

Rated voltage

32 V

Rated impulse voltage

0.8 kV

Pollution degree

3

Material

- Insulator

Liquid Crystaline Polymer

- Outer conductor

Zinc alloy

Contact resistance

≤ 4 mΩ

Limiting temperatures

-40 °C ... +125 °C

Flammability acc. to UL 94

V 0

Outer surface finish

Nickel

Cable diameter

5 ... 12 mm

Han

®

D-Sub crimp contacts

Crimp terminal

- mm²

0.08 ... 0.52 mm²

- AWG

28 ... 20

Turned contacts

Performance level 1

Accessories

Crimp flange

see page 06.98

Crimp ferrule

see page 06.98

Cable clamp

see page 06.98
