06

.

15

Han

Modular

6 B

"https://b2b.harting.com/ebusiness/en/

09 14 006 0303

"

"https://b2b.harting.com/ebusiness/en/

09 14 006 0313

"

10 B

"https://b2b.harting.com/ebusiness/en/

09 14 010 0303

"

"https://b2b.harting.com/ebusiness/en/

09 14 010 0313

"

16 B

"https://b2b.harting.com/ebusiness/en/

09 14 016 0303

"

"https://b2b.harting.com/ebusiness/en/

09 14 016 0313

"

24 B

"https://b2b.harting.com/ebusiness/en/

09 14 024 0303

"

"https://b2b.harting.com/ebusiness/en/

09 14 024 0313

"

A

B

C

6 B

10 B
16 B
24 B

"https://b2b.harting.com/ebusiness/en/

09 14 000 9960

"

"https://b2b.harting.com/ebusiness/en/

09 14 000 9960

"

Han-Modular

®

Hinged frames

Stock items in bold type

1) Distance max. 20.5 mm

2) Hinged frames can be used either in hood or housing

Both different markings must be used for one connector!

Part number for Hood/Housing 2)

Identification

Size

Marking A ... F Marking a ... f

Drawing

Dimensions in mm

Locking element

for hinged frames

(20 pieces

per bloc)

Ideal to

pre-assemble the

hinged frames

Hinged frame

for 2 modules

Hoods

Housings

Hinged frame

for 3 modules

Hinged frame

for 4 modules

Hinged frame

for 6 modules

Panel cut out

Size

A

B

C

6 B

35

44

52

10 B

49

57

66

16 B

64

77.5

85.5

24 B

94

104

112
