Han ® C module
690 V 40 A
Stock items in bold type
Number of contacts
3
Part number
Identification Male insert (M) Female insert (F) Drawing Dimensions in mm
Crimp terminal
Order crimp contacts
separately
Contact arrangement
view from termination side
Wire gauge Part number
Identification (mm²) Male contact Female contact Drawing Dimensions in mm
Crimp contacts
Power contacts
Wire gauge
Stripping
length
1.5
2.5
4
6
10
1.75
2.25
2.85
3.5
4.3
9.5 mm
9.5 mm
9.5 mm
9.5 mm
12 mm
silver plated 1.5
2.5
4
6
10
