Han ® GigaBit module
Features
• Shielding bus separate from housing potential
• Ideal for the transmission of sensetive signals
(e.g. bus signals)
• Usuable for Gigabit Ethernet Cat. 6
A
Technical characteristics
Specifications DIN EN 60 664-1
DIN EN 61 984
Approvals
Inserts
Number of contacts 8
Insulation resistance ≥ 10 10 Ω
Material polycarbonate
Limiting temperatures -40 °C ... +125 °C
Flammability acc. to UL 94 V 0
Mechanical working life
- mating cycles ≥ 500
GigaBit contacts
Number of contacts 8 + shielding
Electrical data
acc. to EN 61 984
5 A 50 V 0.8 kV 3
Rated current 5 A
Rated voltage 50 V
Rated impulse voltage 0.8 kV
Pollution degree 3
Rated voltage
acc. to UL < 30 V
Material
- Insulator polycarbonate
- Outer conductor zinc alloy
Contact resistance ≤ 4 mΩ
Limiting temperatures -40 °C ... +85 °C
Flammability acc. to UL 94 V 0
Outer surface finish nickel
Cable diameter 5 ... 12 mm
D-Sub crimp contacts
Crimp terminal
- mm² 0.08 ... 0.52 mm²
- AWG 28 ... 20
turned contacts Performance level 1
Accessories
Crimp flange see page 06.98
Crimp ferrule see page 06.98
Cable clamp see page 06.98
