Northern Connectors Harting Han-Modular Connectors - Manual (Page 38)

06
.
38
Han
Modular
Technische Kennwerte Features Technical characteristics
Specifications DIN EN 60 664-1
DIN EN 60 61984
Inserts
Number of contacts 1 / 4
Electrical data accd. to
DIN EN 61 984
Power contacts
70 A 1000 V 8 kV 3
Rated current 70 A
Rated voltage 1000 V
Rated impulse voltage 8 kV
Pollution degree 3
Signal contacts
16 A 400 V 6 kV 3
Rated current 16 A
Rated voltage 400 V
Rated impulse voltage 6 kV
Pollution degree 3
Insulation resistance ≥ 10 10 Ω
Material Polycarbonate
Limiting temperatures
-40 °C ... +125 °C
Flammability acc. to UL 94 V 0
Mechanical working life ≥ 500 mating cycles
Power Contacts
Material Copper alloy
Surface
- hard-silver plated 3 µm Ag
Contact resistance ≤ 0.5 mΩ
Axial screw terminal
- geometric wire gauge 6 ... 22 mm²
- AWG 8 ... 4
- Hexagonal drive SW 2.5
Tightening torque
Stripping length
Signal Contacts
Material Copper alloy
Surface
- hard-silver plated 3 µm Ag
- hard-gold plated 2 µm Ag over 3 µm Ni
Contact resistance ≤ 1 mΩ
Crimp terminal
- mm² 0.14 ... 4 mm²
- AWG 26 ... 12
• One contact (70 A) for power circuits
• Four contacts (16 A) for signal circuits
• Combination of power and signal contacts
in one module
Han-Modular ® 70 A Hybrid Module
mm 2 6 10 16 22
mm 11 +1 11 +1 11 +1 12.5 +1
mm 2 6 10 16 22
Nm 2 3 4 4
