MTS SWIFT 10 MC Sensor User Manual
Page 88
SWIFT 10 MC Sensors
88
Road Simulator
Installing the Transducer
Assembling the Slip Ring Side (rear shown)
6 Conductor, Board 1,
9-pin Slip Ring Connector
5 Conductor, Board 2,
9-pin Slip Ring Connector
Inner Hub Assembly
(Slip Ring/Encoder Side)
Axle Spacer
Inner Hub/
Brake Disk
Adapter
Axle Sleeve
Slip Ring/
Encoder
Pin Hole for
Setscrew
Slip Ring Wires to
System Cable Assembly
Load
Spacer
Slip Ring
Keyway
S10MC-13R
Inner Hub/Brake
Disk Adapter
Axle
Spacer
Axle
Sleeve
Slip Ring/
Encoder
Load
Spacer
Sealed
Bearing
Oil
Seal
6 Conductor, Board 1,
9-pin Slip Ring Connector
(note orientation of dovetail
on the connector shell)
5 Conductor, Board 2,
9-pin Slip Ring Connector
(note orientation of dovetail
on the connector shell)
Square Head
Setscrew Hole
Stock
Brake Disk
