Road Simulator
SWIFT 10 MC Sensors Installing the Transducer 83
Equipment required
This procedure requires one person. To install the transducer, you will need the
following equipment:
• Spindle adapter spacers (see next figure)
• Adapters to 329 simulator
• Small set of metric hex-head wrenches
• Metric socket head drive set (up to 14 mm) with extension
• Transducer mounting bolts (per transducer)
1
20 size M8 X 1.25 mm X 50 mm long
8 size M8 X 1.25 mm X 75 mm long
8 washers 17 mm O.D. X 8.4 mm I.D.
• Torque wrenches, capable of the following ranges:
19–38 N•m (14–28 lbf•ft)
95 N•m (70 lbf•ft)
• Torque wrenches, capable of the following ranges:
24–74 N•m (18–55 lbf•ft),
203–815 N•m (150-600 lbf•ft);
108–325 N•m (80–240 lbf •ft)
93 N•m (69 lbf•ft)
• Cables (transducer and BNC, plus customer-supplied from transducer
interface to data recorder)
• Tie wraps
• Data recorder
• Power supply–12 V DC or suitable 12 V DC vehicle battery 2
1. Lengths shown are for reference only. Verify lengths for your specific
design.
2. Not all vehicles have alternators to maintain the charge to the vehicle battery
if the battery is also used by the SWIFT sensor and the data acquisition
system. Additional batteries and/or chargers may be necessary.
