SWIFT 10 MC Sensors

42

TI2SHUNT - Transducer Interface Shunt

Software Utilities

Option 2

Use this to set the shunt tolerance. When selected, the following is displayed:

Option 3

Use this option to apply a shunt to each bridge individually, read the output of the
bridge, compare the result with the value stored in the Transducer Interface and
display the difference each bridge. See the table on the next page. The shaded
fields are the bridge being shunted. The actual sequence depends on the
transducer wiring. Note that this option does not update the shunt measured
values or error status.

Enter choice: 2

The current shunt tolerance is 2%

Enter new shunt tolerance in percent?

Enter choice: 3

FX1

FX2

FY1

FY2

FY3

FY4

FZ1

FZ2

Unshunted:

-0.00067

-0.00060

0.00000

0.00000

0.00000

0.00000

0.00054

-0.00067

Shunted1:

-0.00100

0.85392

0.00000

0.00000

0.00000

0.00000

-0.00013

-0.00100

Differ1:

-0.00033

0.85452

0.00000

0.00000

0.00000

0.00000

-0.00067

-0.00033

Unshunted:

-0.00067

-0.00027

0.00000

0.00000

0.00000

0.00000

0.00020

-0.00100

Shunted2:

-0.00100

-0.00027

0.00000

0.00000

0.00000

0.00000

0.00054

0.85388

Differ2:

-0.00033

0.00000

0.00000

0.00000

0.00000

0.00000

0.00033

0.85488

Unshunted:

-0.00067

-0.00094

0.00000

0.00000

0.00000

0.00000

-0.00047

-0.00067

Shunted3:

0.85320

-0.00060

0.00000

0.00000

0.00000

0.00000

0.00020

-0.00100

Differ3:

0.85387

0.00033

0.00000

0.00000

0.00000

0.00000

0.00067

-0.00033

Unshunted:

-0.00134

-0.00060

0.00000

0.00000

0.00000

0.00000

0.00054

-0.00067

Shunted4:

-0.00100

0.00007

0.00000

0.00000

0.00000

0.00000

0.85396

-0.00067

Differ4:

0.00033

0.00067

0.00000

0.00000

0.00000

0.00000

0.85342

0.00000

Unshunted:

-0.00100

-0.00094

0.00000

0.00000

0.00000

0.00000

0.00020

-0.00033

Shunted5:

-0.00067

-0.00060

0.00000

0.00000

0.00000

0.00000

0.00054

-0.00100

Differ5:

0.00033

0.00033

0.00000

0.00000

0.00000

0.00000

0.00033

-0.00067

Unshunted:

-0.00067

-0.00027

0.00000

0.00000

0.00000

0.00000

0.00020

-0.00100

Shunted6:

-0.00134

-0.00094

0.00000

0.00000

0.00000

0.00000

0.00054

-0.00100

Differ6:

-0.00067

-0.00067

0.00000

0.00000

0.00000

0.00000

0.00033

0.00000

Unshunted:

-0.00067

-0.00060

0.00000

0.00000

0.00000

0.00000

-0.00013

-0.00067

Shunted7:

-0.00067

-0.00027

0.00000

0.00000

0.00000

0.00000

-0.00013

-0.00067

Differ7:

0.00000

0.00033

0.00000

0.00000

0.00000

0.00000

0.00000

0.00000

Unshunted:

-0.00100

-0.00060

0.00000

0.00000

0.00000

0.00000

0.00020

-0.00100

Shunted8:

-0.00067

-0.00060

0.00000

0.00000

0.00000

0.00000

0.00020

-0.00067

Differ8:

0.00033

0.00000

0.00000

0.00000

0.00000

0.00000

0.00000

0.00033
