Specifications
SWIFT 10 MC Sensors Hardware Overview 25
Transducer Center-of-Gravity
Transducer Center-of-Gravity and Inertia Specifications
M ATERIAL
A LUMINUM T ITANIUM
X
cg
0.0 mm 0.000 in 0.0 mm 0.000 in
Y
cg
18.0 mm 0.710 in 18.0 mm 0.710 in
Z
cg
0.0 mm 0.000 in 0.0 mm 0.000 in
I
xx 26 kg·cm 2 9 lbm·in 2 42 kg·cm 2 14 lbm·in 2
I
yy 50 kg·cm 2 17 lbm·in 2 80 kg·cm 2 27 lbm·in 2
I
zz 26 kg·cm
2
9 lbm·in
2
42 kg·cm
2
14 lbm·in
2
