MTS SWIFT 10 MC Sensor - Manual (Page 26)

SWIFT 10 MC Sensors 26
Specifications
Hardware Overview
Transducer Interface
P ARAMETER S PECIFICATION
Physical
Height
Width
Depth
Weight
Rack Mounting Kit 28 mm (1.100 in)
213 mm (8.375 in)
171 mm (6.750 in.)
*
0.907 kg (30 oz)
Optional
* Add 25.4 mm (1.0 in) for ground lugs.
Environmental
Ambient temperature
Relative humidity
Protection 0° C (32° F) to 50° C (122° F)
0 to 90%, non-condensing
IP64 (complete dust protection, projected water
from all directions)
Power Requirements
Input voltage
Fuses 10–28 V DC
Internal thermal, self-resetting
Power Consumption 4 Watts maximum without transducer of encoder
6 Watts typical with transducer and encoder at 12
V DC
Angular velocity
Encoder limit
Processing limit
Encoder resolution 2,200 rpm maximum
10,000 rpm maximum
2048 counts per revolution
(512 pulses with quadrature)
Time delay (encoder tick to main output stable) 150 µs (typical)
Transducer cable length 100 ft maximum
Analog outputs
Voltage
Capacitive load
Current
Noise at output, with typical gains
±10 V range
†
(force and moment outputs)
0–5 V sawtooth (angle output)
0.01 µF maximum
2 mA maximum
7 mVpp, DC - 500 Hz (typical)
15 mVpp, DC - 500 Hz (maximum)
† Standard from MTS. Other full scale voltages can be evaluated and may be provided at special
request.
