5.6 Digital frequency output X9 (Option)
The connection of drives via digital frequency allows a simple and
precise control of multi-motor systems. The digital frequency output
X9 can be used here as digital frequency encoder, e.g. for parallel
or slave drives.
Assignment of socket X9
Pin Name Input/Output Explanation
1
2
3
4
5
6
7
8
9 B
A\
A
---
GND
---
---
5V
B\ Output
˝Output
Output
Output
Output
2nd encoder signal
1st encoder signal inverse
1st encoder signal
Not used
Internal ground
Not used
Nt used
Lamp check
2nd encoder signal inverse
Depending on the relationship of the drive controlled via X9, you
can program under C008 if the input signals at X5 are to be output
unchanged or if an internal set-value signal is to be processed.
Internal set-value sources are:
•
Main set-value (Set-value 1/JOG frequency)
•
Ramp generator output (main set-value)
•
Total set-value (total of ramp generator outputs)
If you have selected an internal set-value signal as digital
frequency, you can also program its setting range under C030. The
frequency of the output signals results from
Output freq. = set-value signal
⋅
max. field freq. (C011)
⋅
constant (C030)
Please note that when processing the selected set-value signal
minor conversion errors may be possible.
Code Parameter Meaning Acceptance
C008 -0-
-2-
-3-
-5- Ouput of input signals at X5
Main set-value
Ramp generator output (main set-value)
Total set-value SH + PRG
C030 -1-
-2-
-3-
-4- 512 pulses/Hz field frequency
1024 pulses/Hz field frequency
2048 pulses/Hz field frequency
4096 pulses/Hz field frequency SH + PRG
