112
10.3.9 High resolution data
Under codes C380 to C382 you can enter very precise set-value
and feedback with a resolution of 14 bit plus sign.
Set-value 1:
Set-value scaled to the maximum frequency. The value of 2
14
corresponds to 100% of the maximum field frequency. The
information is identical with that under C046, with the difference
that you can read the controller value directly thus excluding
conversion errors.
Total set-value:
Total of main set-value 1 and set-value 2, each behind the ramp
generator, scaled to the maximum field frequency. The total set-
value corresponds to the set-value of the PI controller in closed-
loop control. The value of 2
14 corresponds to 100% of the
maximum field frequency.
Feedback of PI controller
Feedback for the PI controller, scaled to the maximum field
frequency. The value of 2
14 corresponds to 100% of the maximum
field frequency. The information is identical with that under C051,
with the difference that you can read the controller value directly
thus excluding conversion errors.
Code Parameter Meaning Acceptance
C380 -16384 to +16384 Set-value 1
C381 -16384 to +16384 Total set-value only display
C382 -16384 to +16384 Feedback of PI controller only display
