Lenze 8615E User Manual
Page 110
108
Code
Name
Parameter
(Factory setting printed in bold)
Acceptance see
page
Your
settings
C210*
Preselection:
Process step
-1-
Process step 1
-2-
Process step 2
...
...
-8-
Process step 8
SH + PRG
94
C211*
Set-value for
C210
-0-
Set-value 1 (C046)
-1-
JOG 1
-2-
JOG 2
...
...
-15-
JOG 15
SH + PRG
94
C212*
Pair of ramp
times for C210
-0-
Standard pair of ramp times
(C012 and C013)
-1-
Additional pair of ramp times 1
-2-
Additional pair of ramp times 2
... ...
-15-
Additional pair of ramp times 15
SH + PRG
94
C213*
Duration for
C210
10.0s
0.0...9900s
(in steps of 10ms from 0.0 to 1s
in steps of 100ms from 1 to 10s
in steps of 1s from 10 to 100s
in steps of 10s from 100to 990s
in steps of 100s from 1000 to 9900s)
ON-LINE
94
C214*
Next step for
C210
-0-
Finish process control
-1-
Process step 1
-2-
Process step 2
...
...
-8-
Process step 8
SH + PRG
94
C220
Acceleration
time for set-
value 2
5.0s
0.0...990s
(in steps of 10ms from 0.0 to 1s
in steps of 100ms from 1 to 10s
in steps of 100ms from 10 to 990s)
ON-LINE
66
C221
Deceleration
time for set-
value 2
5.0s
0.0...990s
(in steps of 10ms from 0.0 to 1s
in steps of 100ms from 1 to 10s
in steps of 100ms from 10 to 990s)
ON-LINE
66
C234*
Load change
damping
0.25
0.00...5.00
(in steps of 0.01)
ON-LINE
96
C238
Frequency
pilot control
-0-
No pilot control
-1-
With set-value pilot control
-2-
With feedback pilot control
[SH + PRG] 74
C239
Frequency
setting range
-0-
Frequency setting range bipolar
-1-
Frequency setting range unipolar
[SH + PRG] 93
C240
Window
Feedback =
set-value
0.5%
0.0...100%
(in steps of 0.1%)
ON-LINE
88,
77
C241
Window ramp
generator
output = input
0.5%
0.0...100%
(in steps of 0.1%)
ON-LINE
87
C249*
Code bank
(only for
LECOM)
0
0...7
SH + PRG
111
C370*
Enable
automation
interface
(LECOM2)
-0-
No communication via automation
interface
-1-
Communication via automation
interface enabled
[SH + PRG] 111
C380
Set-value 1
(Process
datum only for
LECOM)
-16384...+16384
(in steps of 1)
112
C381
Total set-value
(process
datum only for
LECOM)
-16384...+16384
(in steps of 1)
1112
C382
Feedback fo
PI controller
(process
datum only for
LECOM)
-16384...+16384
(in steps of 1)
112
