6.6
RFI filters
Advantage of using a RFI filter:
•
Reduction of high-frequent radio interference.
Please note:
•
Because of the generation of leakage currents, the RFI filters
must be connected to earth. The RFI filter must always be
connected to earth at first even if you only want to test the
system.
Otherwise, the system is not protected against shock.
•
The filters listed in the following can be connected to the 400 V
mains.
If you need filters for mains voltages of 460 V or 480 V, please
contact the factory.
6.6.1 Ratings of RFI filters
The ratings of the RFI filters depend on the mains current which is
permanently applied.
Operation at rated power (factory setting)
Inverter type
Rated filter current
Order number
8601...8603
8 A
EZF3-008A001
8604...8606
16 A
EZF3-016A001
8607...8608
25 A
EZF3-025A001
8609...8610
36 A
EZF3-036A001
8611
50 A
EZF3-050A004
8612...8613
80 A
EZF3-080A001
8614
110 A
EZF3-110A001
8615
180 A
EZF3-180A001
Operation at increased power
Inverter type
Rated filter current
Order number
8601...8603
8 A
EZF3-008A00
8604...8606
16 A
EZF3-016A001
8607
25 A
EZF3-025A001
8608
36 A
EZF3-036A001
8609...8610
50 A
EZF3-050A004
8611...8612
80 A
EZF3-080A001
8613...8614
110 A
EZF3-110A001
8615
180 A
EZF3-180A001
Operation at maximum power
Inverter type
Rated filter current
Order number
8601...8602
8 A
EZF3-008A001
8603...8604
16 A
EZF3-016A001
8606
25 A
EZF3-025A001
8608...8609
50 A
EZF3-050A004
8610
80 A
EZF3-080A001
8612
110 A
EZF3-110A001
8613...8614
180 A
EZF3-180A001
