Wiring the device modules

Safety modules

6

l

86

EDK94SH104 DE/EN/FR/ES/IT 5.1

Displays

Pos.

Colour

State

Description

MS

Green

On

Drive−based safety is initialised faultlessly.

Blinking

Drive−based safety is initialised faultlessly. Internal
communication to the standard device is not possible.

Off

Drive−based safety is not initialised.
Acknowledgement is not possible.

EN

Yellow

On

Controller enabled

Off

Non−safe display "STO"

ME

Red

On

System error:

l

After a serious internal error, STO is activated.

l

Can only be reset by switching the 24V supply.

Blinking

Error:

l

After an internal error or an error at the safe inputs, a
standstill function is activated.

l

The safety class is quit.

l

Acknowledgement is possible.

Flashing

Fault:

l

A monitoring function has responded and activated a
standstill function.

l

The safety class is not quit.

l

Acknowledgement is possible.

Off

Error−free operation

PS

Red

On

Error PROFIsafe:

l

Communication is not possible.

l

Acknowledgement is possible.

Blinking

No valid PROFIsafe configuration

Off

PROFIsafe is error−free.

DE

Red

On

The module is not accepted by the standard device (see notes
given in the documentation for the standard device).
