Page 46
l
46
EDK94SH104 DE/EN/FR/ES/IT 5.1
Overview
Standard device
0
Design
Pos.
Description
HighLine
StateLine
MXI1
Module slot for extension 1, e.g. communication
ю
ю
MXI2
Module slot for extension 2, e.g. communication
þ
o
MMI
Module slot for memory modules
ю
ю
MSI
Module slot for safety modules
ю
ю
X1
System bus (CAN), under the cover
þ
o
X2
24−V supply and state bus
ю
ю
X3
Analog inputs and analog outputs
2/2
1/0
X4
Digital outputs
4
1
X5
Digital inputs
8
4
X6
Diagnostics
ю
ю
X7
Resolver
ю
ю
X8
Encoder
ю
ю
2
Lower cap
ю
ю
3
Nameplate, retractable
ю
ю
4
Upper cap
ю
ю
8
EMC clamp
3
3
X100
Mains / DC−bus voltage
ю
ю
X105
Motor / external brake resistor
ю
ю
X106
Motor temperature monitoring
ю
ю
X107
Control of motor holding brake
Optional
Optional
6 7
EMC wire clamp
Device size 6:
Æ 10 ... 20 mm and Æ 15 ... 28 mm
Device size 7:
Æ 15 ... 28 mm and Æ 20 ... 37 mm
2
2
9
Internal thread for M6 eye bolt (not included in the scope of supply)
4
4
:
Strain relief and lifting aid, removable
2
2
The LED display enables fast indication of several operating states.
LED
Labelling
Colour
Description
CAN−RUN
green
CAN bus o.k.
Inoperable when "StateLine" design is
used
CAN−ERR
red
CAN bus error
DRIVE READY
green
Standard device is ready for operation
DRIVE ERROR
red
Error in the standard device or due to the application
24 V
green
24−V supply voltage o.k.
SSP94LED01
USER
yellow
Message parameterised by the application
Pos.
Symbol
Description
5
{
Long discharge time: All power terminals carry hazardous voltages for at
least 3 minutes after mains disconnection!
}
High discharge current: Fixed installation and PE connection to EN 61800−5−1
required!
'
Electrostatic sensitive devices: Before working on the device, personnel must
ensure that they are free of electrostatic charge!
