Mounting the device

Dimensions

4

l

59

EDK94SH104 DE/EN/FR/ES/IT 5.1

4

Mounting the device

)

Note!

The devices must be installed in housings (e.g. control cabinets) to meet
applicable regulations.

4.1

Dimensions

SSP94Mas01

Fig. 4−1

Dimensions [mm]

Dimensions [mm]

Weight

Device

size

Type

a

b

b1

b2

e

c1

d

g

m

[kg]

E94ASxE0324

206

606

556

630

294

170

585

6.5

12.5

26.5

6

E94ASxE0474

E94ASxE0594

E94ASxE0864

266

706

655

729

370

230

685

42

7

E94ASxE1044
