Page 64

Wiring the device
Example circuit
l
64
EDK94SH104 DE/EN/FR/ES/IT 5.1
5.2
Example circuit
L3
N
PE
L1
L2
F1...F3
F4
K1
K1
K1
L1
L2
L3
E94ASxExxxx
X100
-UG
O
I
+UG
R
B
R
B
U
Rb1 Rb2
V
W
X105
BD1 BD2
X107
X7
T1 T2
X106
M
3~
R
Y
ϑ
ϑ
EYF...
7 2
+
-
+
-
+
+
X2
24E
SB
GE
+
-
X3
+
-
A1-
A1+
RFR
X5
GI
RFR
+
-
Z1
SSP94PSP67
E94ASxExxxx
Servo axis module 9400 Single
F1 ... F4
Fuses
Z1
Toroidal core, effective in the high−frequency range 30 ... 60 MHz
"
HF−shield termination through large−surface connection to functional earth
EYF...
System cable − resolver feedback
RFR
Controller enable
K1
Mains contactor
R
Resolver
RB
Brake resistor
Y
Motor holding brake (an optimum motor brake control)
Speed setpoint selection via analog input 1 (−10 ... 0 ... +10 V)
Voltage source for the motor holding brake
24−V voltage source for digital inputs according to IEC 61131−2
24−V voltage source for the control electronics
