Technical data
Electrical data
3
l
58 EDK94SH104 DE/EN/FR/ES/IT 5.1
3.2 Electrical data
Input data
Basis of the data
Mains Voltage Voltage range Frequency range
U
LN
[V] U
LN
[V] f [Hz]
3/PE AC 230 180 − 0 % ... 264 + 0 % 45 − 0 % ... 65 + 0 %
3/PE AC 400 320 − 0 % ... 440 + 0 % 45 − 0 % ... 65 + 0 %
3/PE AC 500 400 − 0 % ... 550 + 0 % 45 − 0 % ... 65 + 0 %
Voltage Frequency Current [A] Number of
phases
[V] [Hz] max. +45 °C  max. +55 °C 
E94ASxE0324 230/400/500 50/60 29.0/29.0/26.0 22.0/22.0/20.0 3
E94ASxE0474 230/400/500 50/60 43.0/43.0/39.0 32.0/32.0/29.0 3
E94ASxE0594 230/400/500 50/60 54.0/54.0/47.0 40.5/40.5/35.3 3
E94ASxE0864 230/400/500 50/60 79.0/79.0/70.0 59.0/59.0/52.0 3
E94ASxE1044 230/400/500 50/60 95.0/95.0/84.0 71.0/71.0/63.0 3
 Temperature in the control cabinet
Output data
Voltage Frequency 1) Current [A] Number of
phases
Type [V] [Hz] max. +45 °C

max. +55 °C

E94ASxE0324 0 − 230/400/500 0 − 599 32.0/32.0/28.0 24.0/24.0/21.0 3
E94ASxE0474 0 − 230/400/500 0 − 599 47.0/47.0/41.0 35.3/35.3/30.8 3
E94ASxE0594 0 − 230/400/500 0 − 599 59.0/59.0/51.6 44.3/44.3/38.7 3
E94ASxE0864 0 − 230/400/500 0 − 599 86.0/86.0/75.3 64.5/64.5/56.4 3
E94ASxE1044 0 − 230/400/500 0 − 599 104/104/91.0 78.0/78.0/68.3 3
 Temperature in the control cabinet
Power loss P
V
[W]
Type when operating with rated output current I
aN
when controller is inhibited
E94ASxE0324 750
75 E94ASxE0474 1050
E94ASxE0594 1122
E94ASxE0864 1500
100
E94ASxE1044 1800
Rated data for internal brake chopper
Switching
threshold
(adjustable)
Minimum
brake resistor
Peak current Peak braking
power
Continuous
current
RMS
Continuous
braking
power
Type U
BRmax
[V] R
Bmin
[ W] I
BRmax
[A] P
BRmax
[kW] I
BRd
[A] P
Bd
[kW]
E94ASxE0324 390/790 9/18.0 43.3/43.9 16.9/34.7 28.5/28.9 7.3/15
E94ASxE0474 390/790 7.5/15.0 52.0/52.7 20.3/41.6 37.9/38.4 10.7/22.0
E94ASxE0594 390/790 7.5/15.0 52.0/52.7 20.3/41.6 44.2/44.8 14.6/30.0
E94ASxE0864 390/790 3.8/7.5 102.6/105.3 40.0/83.2 75.5/77.5 21.6/45.0
E94ASxE1044 390/790 3.8/7.5 102.6/105.3 40.0/83.2 83.5/85.7 26.5/55.0
