9 Function library L_IODrvEtherCAT.lib
9.7 Data types
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
9.7.6 L_ETC_ERRORCODE
The type L_ETC_ERRORCODE describes all possible EtherCAT error codes that can be output at the
eErrorCode output of the EtherCAT function blocks.
A detailed description of the EtherCAT error codes is provided in the chapter entitled "Diagnostics":
 General error codes (L_ETC_ERRORCODE) ( 183)
 SDO abort codes ( 195)
9.7.7 L_ETC_IOCTLOPARMS
The L_ETC_IOCTLOPARMS type describes the reference to the I/O buffer e.g. for the L_ETC_IoControl
(FUN) ( 139) function.
9.7.8 L_ETC_LANGUAGE
The L_ETC_LANGUAGE type describes the languages in which e.g. an error text can be output via the
L_ETC_GetErrorString (FUN) ( 143) function.
9.7.9 L_ETC_SLAVE_PORTS
The type L_ETC_SLAVE_PORTS describes ports 0 ... 3 of the EtherCAT slaves.
TYPE L_ETC_IOCTLOPARMS :
STRUCT
pbyInBuf : POINTER TO BYTE; // Input data buffer
dwInBufSize : DWORD; // Size of input data buffer in bytes
pbyOutBuf : POINTER TO BYTE; // Output data buffer
dwOutBufSize : DWORD; // Size of output data buffer in bytes
pdwNumOutData : POINTER TO DWORD; // Number of output data bytes stored in
// output data buffer
END_STRUCT
END_TYPE
TYPE L_ETC_LANGUAGE :
(
eng, // english
de // german
);
END_TYPE
TYPE L_ETC_SLAVE_PORTS :
STRUCT
Port0 : BYTE; // Slave port 0
Port1 : BYTE; // Slave port 1
Port2 : BYTE; // Slave port 2
Port3 : BYTE; // Slave port 3
END_STRUCT
END_TYPE
