STM-2XM Operating Manual
Analog output 1 to 4 function . . . . Determines the function of each of the
analog outputs (refer to section 2.2.3 on
page 2-5 for details on wiring analog
outputs). (See Table 4-3 .)
Table 4-3 Analog output functions
Setting Description
0: Zero volts Output is disabled
1: +10 V Fixed +10 V Fixed
2: -10 V Fixed -10 V Fixed
3: Computer controlled Output is computer set value
4: Rate Deviation, Channel 1, 1000 Å/S Rate Deviation, Channel 1, 1000 Å/s
5: Rate Deviation, Channel 1, 10 Å/S Rate Deviation, Channel 1, 10 Å/s
6: Rate, Channel 1, 1000 Å/S Rate, Channel 1, 1000 Å/s
7: Rate, Channel 1, 10 Å/S Rate, Channel 1, 10 Å/s
8: Thickness, Channel 1, 999 Å Thickness Recorder, Channel 1, 999 Å
9: Thickness, Channel 1, 99.9 Å Thickness Recorder, Channel 1, 99.9 Å
10: Rate Deviation, Channel 2, 1000 Å/S Rate Deviation, Channel 2, 1000 Å/s
11: Rate Deviation, Channel 2, 10 Å/S Rate Deviation, Channel 2, 10 Å/s
12: Rate, Channel 2, 1000 Å/S Rate, Channel 2, 1000 Å/s
13: Rate, Channel 2, 10 Å/S Rate, Channel 2, 10 Å/s
14: Thickness, Channel 2, 999 Å Thickness Recorder, Channel 2, 999 Å
15: Thickness, Channel 2, 99.9 Å Thickness Recorder, Channel 2, 99.9 Е
