STM-2XM Operating Manual
25 CSID_SUP_INP2P1
Input function Channel 2 #1 Value 0 to 7 (see
)
26 CSID_SUP_INP2P2
Input function Channel 2 #2 Value 0 to 7 (see
)
27 CSID_SUP_INP2P3
Input function Channel 2 #3 Value 0 to 7 (see
)
28 CSID_SUP_INP2P4 Input
function Channel 2 #4 Value 0 to 7 (see
)
29 CSID_SYSMODE
Operational mode
sysmode_class
0 - sysmode_simplex1
1 - sysmode_simplex2
2 - sysmode_backup
3 - sysmode_average
4 - sysmode_alloy
5 - sysmode_independent
NOTE:
Not all values are
available.
Available values are
dependent on the value stored
in the CSID_SUP_SNSR
parameter. An invalid value
returns an error.
Invalid values may be made
available by selecting another
value for CSID_SUP_SNSR
than the value currently
programmed.
30 CSID_SYSTESTMODE
System test mode
Simulates a rate based on
source shutter opening.
Is cleared to False/TestOff
every time a new
reset/powerup.
0 - False/TestOff
1 - True/TestOn
31 CSID_SYSASRC
Active source (channel)
Not meaningful in dual
channel modes, such as
Independent and Alloy.
0 - Channel 1
1 - Channel 2
32 CSID_SYSDISP
Display mode (thick/mass)
sysdisp_class
Effects numeric display and
chart plot data.
0 - Thickness
1 - Mass
Table 5-3 E/F command (continued)
#
Command Structure
Comments
Values
