STM-2XM Operating Manual
5.8.10 Command: P
Command Type . . . . . . . . . . . . . . . . Status
Command Structure . . . . . . . . . . . . . QMONAD_class ItemID
Syntax . . . . . . . . . . . . . . . . . . . . . . . Pn
Description . . . . . . . . . . . . . . . . . . . . Displays status information for STM-2XM,
where n is 1 to 14.
Parameters. . . . . . . . . . . . . . . . . . . . (See
.)
Table 5-6 P command
#
Command Structure
Description
1
QMONAD_STRCOVEN
String return 1PN
2
QMONAD_BADNV
Readable boolean as 0/1 memloss sticky
3
QMONAD_SYST_ID
TRAP IDENT major # displays as numeric
4
QMONAD_SYST_MOD
TRAP TYPE minor # displays as numeric
5
QMONAD_CODSIG
Displays as numeric 0 to 65535 16 bit CRC
6
QMONAD_INPSTATES
Displays as numeric 0 to 255 as bit vector
LSB 1 weight in input 1, MSB 128 is input 8
7
QMONAD_OUTSTATES
Displays as numeric 0 to 255 as bit vector
LSB 1 weight in output 1, MSB 128 output 8
8
QMONAD_
Numeric value of AlloyState_class
Value 0 to 12 (see
9
QMONAD_ASNSR
Numeric value of Active sensor 0/1/2
0 - Channel 1
1 - Channel 2
2 - BOTH/DUAL
10 QMONAD_INTSRLNO
Internal serial number as fetched from
FRAM
0 if unknown
11 QMONAD_BUILDTYP
Build type from FRAM, harvested at
power up
0 if FRAM bad
12 QMONAD_CPLDVRSN
Numeric code 0 to 255, CPLD I.P. cpld_rev
version identification field
13 QMONAD_WARNVALUE
WARNVALUE is an internal warning
system code, 0 to 255 . 0 is no warning. 128
is test warning posted with test combination
lock code (RLRL R2 L R2 L R2). 250 means
firmware mismatched/invalid with hardware
in use, or circuit failure, or both.
14 QMONAD_HW_CFG
HW_CFG 0 to 15 value based on
H/W platform
