STM-2XM Operating Manual
5.8.5 Command: G/H
Command Type . . . . . . . . . . . . . . . . Query
Command Structure . . . . . . . . . . . . . GCCchannelID_class Pid CHANNEL
GROUP
Syntax . . . . . . . . . . . . . . . . . . . . . . . G1,channel index 0/1
Description . . . . . . . . . . . . . . . . . . . . Queries active film of Channel X as index
0/1.
Command Type . . . . . . . . . . . . . . . . Update
Command Structure . . . . . . . . . . . . . CCHID_AFILM(1)
Syntax . . . . . . . . . . . . . . . . . . . . . . . H1,channel index 0/1=value
Description . . . . . . . . . . . . . . . . . . . . Updates active film.
Response . . . . . . . . . . . . . . . . . . . . . Active film for Channel X, value returned is 1
to 15 for Films 1 to 15. Same used to store
Syntax G1,0/1 H1,0/1=1 to 15
5.8.6 Command: I/J
Command Type . . . . . . . . . . . . . . . . Query
Command Structure . . . . . . . . . . . . . CFID_class Pid FILM GROUP
Syntax . . . . . . . . . . . . . . . . . . . . . . . IF,n
Description . . . . . . . . . . . . . . . . . . . . Queries Film parameters, where F is film
number 1 to 15 and n is parameter 1 to 21.
Command Type . . . . . . . . . . . . . . . . Update
Syntax . . . . . . . . . . . . . . . . . . . . . . . JF,n=value
Parameters. . . . . . . . . . . . . . . . . . . . (See Table 5-4 .)
Table 5-4 I/J command
# Command Structure Name Comment Default
1 CFID_FILMNAM Name Value string of eight characters
from set {A-Z0-9_ }.
Leading spaces are significant.
Trailing spaces are eliminated.
In film lists, names are displayed
right justified, with the rightmost
non-space character displayed
right most.
In SET ACTIVE FILM list, they are
displayed left justified, with entirely
empty string displayed as "- NO
NAME -" . Via RS-232 or Screen
editor, all valid strings can be
entered and displayed. _NO
NAME
for all 15
films
