STM-2XM Operating Manual
Paste film . . . . . . . . . . . . . . . . . . . . Click to paste the film parameters for the
displayed film in the film on clipboard box
onto the current film parameters displayed,
thereby replacing the values for the current
film.
All films pane
Use the spin box to increment or decrement the values for each of the parameters
listed below.
EDITING film# . . . . . . . . . . . . . . . . . 1 to 15
Name . . . . . . . . . . . . . . . . . . . . . . . . 8 character maximum
Density . . . . . . . . . . . . . . . . . . . . . . 0.40 to 99.99 g/cm
3
Z-Ratio . . . . . . . . . . . . . . . . . . . . . . . 0.100 to 9.999
Tooling. . . . . . . . . . . . . . . . . . . . . . . 10 to 999.9%
Setpoint mass. . . . . . . . . . . . . . . . . 0.00 to 9999.99 µg/cm²
Setpoint Thickness . . . . . . . . . . . . 0.000 to 999.999 kÅ
End mass . . . . . . . . . . . . . . . . . . . . 0.00 to 9999.99 µg/cm²
End Thickness . . . . . . . . . . . . . . . . 0.000 to 999.999 kÅ
Use Backup. . . . . . . . . . . . . . . . . . . Select to enable the use of the backup crystal
(refer to
).
Setpoint Time . . . . . . . . . . . . . . . . . 00:00:00 to 9:59:59 h:mm:ss
Desired Rate . . . . . . . . . . . . . . . . . . 0.00 to 99.99 µg•s/cm²
Desired Rate . . . . . . . . . . . . . . . . . . 0.0 to 999.9 Å/s
Do shutter delay? . . . . . . . . . . . . . . Select to enable shutter delay (refer to
Do rate sampling . . . . . . . . . . . . . . Select to enable rate sampling (refer to
Sampling interval . . . . . . . . . . . . . . 00:00:00 to 9:59:59 h:mm:ss
Sampling Dwell. . . . . . . . . . . . . . . . 00:00:00 to 9:59:59 h:mm:ss
Do time/power. . . . . . . . . . . . . . . . . Select to enable time/power upon crystal fail
(refer to
).
Xtal min life . . . . . . . . . . . . . . . . . . . 0 to 99%
Force fail on min life . . . . . . . . . . . Select to enable an automatic crystal fail
upon reaching the minimum crystal life input
(refer to
).
# Samples . . . . . . . . . . . . . . . . . . . . 1 to 50
Good Rate Tolerance . . . . . . . . . . . 0 to 50%
