44
Sensor Type Temperature
Range(°C)
Temperature
Range(°F)
E -270~1000 -518~1832
J -210~1200 -140~2192
S -50~1768 -122~3236
T -270~400 -518~752
RTD (PT 100) -200~850 -392~1562
Table 3-1
3.7.1 Thermocouple Measurements
Connect the thermocouple adapter to the banana jacks on the front
panel. The difference between each type is subject to the patch thermal
leads.
※ Note: Only connection via the front panel can be used for temperature
measurements.
How to measure thermocouple
① Use terminals switch to select terminals on the front panel.
② To measure thermocouple must be via thermocouple adapter and the
low thermal patch leads as shown in Figure 3-12. (When the
mentioned modules are well connected as the following figure, please
go to the next step.)
③ Configure the thermocouple type and unit using CONFIG + SHIFT +
TEMP, such as K TYPE and ºC. When ready, press ENTER button.
