BNC 1201 - 6 1/2 Digit Digital Multimeter User Manual
Page 132

133
Function
Range
Resolution
Shunt
Resistance
1 Year
(23°C ± 5°C)
10.000000mA
10 nA
5.1Ω
0.050 + 0.020
100.00000mA
100 nA
5.1Ω
0.050 + 0.005
1.000000A
1 uA
0.1Ω
0.100 + 0.010
DCI
(DC
Current)
3.00000A
10 uA
0.1Ω
0.120 + 0.020
Function
Range
Resolution
Test Current
1 Year
(23°C ± 5°C)
100.0000 Ω
100 uΩ
1 mA
0.010 + 0.004
1.000000 KΩ
1 mΩ
1 mA
0.010 + 0.001
10.00000 KΩ
10 mΩ
100 uA
0.010 + 0.001
100.0000 KΩ
100 mΩ
10 uA
0.010 + 0.001
1.000000 MΩ
1 Ω
5 uA
0.010 + 0.001
10.00000 MΩ
10 Ω
500 nA
0.040 + 0.001
Resistance
4
100.0000 MΩ
100 Ω
500 nA||10
MΩ
0.800 + 0.010
Diode Test
1.0000V
10 uV
1mA
0.010 + 0.020
Continuity
1000.00KΩ
10 mΩ
1mA
0.010 + 0.030
4 a. Specifications are for 4-wire ohms. For 2-wire ohms, use Math
Null function
b. Max. Lead Resistance: 10% of range per lead for 100Ω and 1KΩ
ranges; 1kΩ per lead for all other ranges.
c. Input protection: 1000 V, all ranges.
