2.2 Features
Resolution: 6.5 digits.
5*7 dot matrix VFD, dual displays with 3-color annunciators.
11 standard measurement functions & 8 math functions.
4 front ground terminal are connected to Chassis.
Stability, Accuracy and Speed (2000RDGS/Sec at 4.5 Digit, 50
RDGS/Sec at 6.5 Digit in 60 Hz)
Multi-Points Scanner Card: Up to 10 Channels. (Optional)
RTD probe Adapter (optional) convenient to use.
Built-in USB and GPIB (Optional) Interfaces.
Easy & Free PC applications.
2.3 1201 Function Introduction
For users to become familiar with the 1201 DMM, we will give a brief
introduction to the basic operations of 1201 DMM. There are three major
parts of 1201: (2.3.1) the front panel, (2.3.2) the display, and
(2.3.3) the rear panel. We will discuss each of them in the following
sections.
2.3.1 The Front Panel
There are different buttons and terminals on the front panel. They are
divided into the following groups: (DISPLAY & POWER), (FUNCTION,
MATH, TRIGGER, MEMORY, SETUP, RANGE, INPUT TERMINALS), and
(FILTER, DIGITS, LOCAL, and SHIFT) as shown in Figure 2-15.
