LN-9400-00.9 76
DynaFlow TM User Manual - Maintenance
Jumper Description Comments
Selects 24 VDC source control or grounded
sink control for digital inputs 12-15.
2-3 = 24 VDC source
1-2 = grounded sink
Selects 24 VDC source control or grounded
sink control for digital inputs 20-23.
2-3 = 24 VDC source
1-2 = grounded sink
Selects 24 VDC source control or grounded
sink control for digital inputs 16-19.
2-3 = 24 VDC source
1-2 = grounded sink
Selects 0-10 VDC or 4-20 ma operation for
the analog control output #2.
2-3 = 0-10 VDC
1-2 = 4-20 mA
Selects 0-10 VDC or 4-20 ma operation for
the analog output #2.
2-3 = 0-10 VDC
1-2 = 4-20 mA
Selects 0-10 VDC or 4-20 ma operation for
the analog set point input #2.
2-3 = 0-10 VDC
1-2 = 4-20 mA
Selects 0-10 VDC or 4-20 ma operation for
the spare analog input #2.
2-3 = 0-10 VDC
1-2 = 4-20 mA
Inputs effected:
Trigger #2
Gun Mask #2
Transparent/PID #2
Total Hold #1
Inputs effected:
Load Mode #2
Analog Hold #2
External Fault #2
MVR Enable #2
Inputs effected:
Run #2
Halt #2
Total Reset #2
Clean #2
To the E/P transducer #2
Actual flow rate for
CHANNEL #2, scaled by
Maximum and Minimum Flow
Rate parameters
Scaled by Maximum and
Minimum Flow Rate
parameters
CHANNEL MODULE P/N: 77206-XX (Obsolete)
DAUGHTER BOARD JUMPER SETTINGS (CHANNEL 2 I/O)
Default Setting
Source
Source
Source
0-10 VDC
0-10 VDC
0-10 VDC
0-10 VDC
2-3
2-3
2-3
2-3
2-3
2-3
2-3
E3
E1
E2
E6
E7
E5
E4
